      FR24-MS101


















      FR24-MS101


      Radar module 24G motion and micro-motion detection module The radar module works in 24G frequency band, uses FMCW frequency modulation continuous wave to detect targets in the set space, combines radar signal processing and correct human body induction algorithms to achieve high-sensitivity human presence State sensing, identifying the human body in motion and static state. Integrated software and hardware solutions such as chips, systems, software, and algorithms














      Features



     5.8G: Integrated high-performance 32-bit MCU, a single chip directly outputs sensing control signals, a real SoC. Powerful performance, rich algorithms can be used, strong scalability, suitable for high-performance scenarios. It supports a standard UART interface, which can be interconnected with other main controllers or sensors, and can also be used as a main control. It can realize presence sensing based on the detection of human breathing.




     24G: The working frequency of this radar module is 24G, using FMCW continuous wave to detect targets in the set space, combining with radar signal processing and correct human body sensing algorithms, to achieve high-sensitivity sensing of human presence, identifying motion and static states Under the human body. Integrated software and hardware solutions such as chips, systems, software, and algorithms.












      Application scenarios











      Product parameter


      modelFR58L4M32-2020S/4020SmodelFR24-MS101/proFR24-MS201
      Power frequency5.8GHz±75MHzPower frequency24~ 24.25GHz 24~ 24.25 GHz
      With MCU32 bitWith MCUOnboard MCUOnboard MCU
      Supply voltage4.5-5.5VSupply voltage3.0~3.6V3.0~3.6V
      Power consumption20MAPower consumption＜50mA35mA
      Beam angle120°Radiated power15dBm (typical value)14dBm (typical value)
      PCB processOrdinary four-layer boardModulationFMCWFMCW
      Communication InterfaceUARTHardware size18*15mm18*15mm
      output signalHigh and low level signalSensing distance20 meters5 meters (presence induction)
      Forward distance1.5MAmbient temperature-40℃~85℃-40℃~85℃
